Standard Hydraulic Rams Steel 51 lb
● In Stock

Standard Hydraulic Rams Steel 51 lb

Standard Hydraulic Rams Single Acting High Quality Rugged Steel Nominal Capacity 55 ton Stroke Length 6 1/4 in Nominal Stroke Length 6 in Effective Push Area 11.04 sq in Max Pressure 9 959 psi Oil Capacity Push 69 cu in Retracted Height 11.13 in Extended Height 17.38 in Outside Dia 5 in Plunger Dia 3.13 in Collar Thread Size 5 In.-12 Base Bolt Circle Dia 3.75 in Base Mounting Thread Size 1/2 In.-13 Center Hole Dia Not Applicable Weight 51 lb Bore Dia 3.75 in

Hubzone SKU 411ZP8
Manufacturer POWER TEAM
Manufacturer Part Number C556C
UNSPSC Code
99999 ⓘ
NAICS Code
N/A ⓘ
Unit of Measure EA
Availability ● In Stock
Lead Time Ships in 1–2 business days
Status ● Active

Your Price

$0.00/ PR

Contract Pricing

Product Overview

Standard Hydraulic Rams Single Acting High Quality Rugged Steel Nominal Capacity 55 ton Stroke Length 6 1/4 in Nominal Stroke Length 6 in Effective Push Area 11.04 sq in Max Pressure 9 959 psi Oil Capacity Push 69 cu in Retracted Height 11.13 in Extended Height 17.38 in Outside Dia 5 in Plunger Dia 3.13 in Collar Thread Size 5 In.-12 Base Bolt Circle Dia 3.75 in Base Mounting Thread Size 1/2 In.-13 Center Hole Dia Not Applicable Weight 51 lb Bore Dia 3.75 in

Full Specifications

Procurement Details

UNSPSC Code 99999
NAICS Code N/A

Documents
