Standard Hydraulic Rams Steel 73.8 lb
● In Stock

Standard Hydraulic Rams Steel 73.8 lb

Standard Hydraulic Rams Single Acting General Purpose Steel Nominal Capacity 55 ton Stroke Length 10 in Nominal Stroke Length 10 in Effective Push Area 20.63 sq in Max Pressure 9 960 psi Oil Capacity Push 110.44 cu in Retracted Height 15.78 in Extended Height 25.78 in Outside Dia 5.16 in Plunger Dia 2.75 in Base Bolt Circle Dia 3.03 in Base Mounting Thread Size M12x1.75 Center Hole Dia Not Applicable Weight 73.8 lb Bore Dia 3.75 in

Hubzone SKU 411ZH2
Manufacturer POWER TEAM
Manufacturer Part Number RGL5510
UNSPSC Code
99999 ⓘ
NAICS Code
N/A ⓘ
Unit of Measure EA
Availability ● In Stock
Lead Time Ships in 1–2 business days
Status ● Active

Your Price

$0.00/ PR

Contract Pricing

Product Overview

Standard Hydraulic Rams Single Acting General Purpose Steel Nominal Capacity 55 ton Stroke Length 10 in Nominal Stroke Length 10 in Effective Push Area 20.63 sq in Max Pressure 9 960 psi Oil Capacity Push 110.44 cu in Retracted Height 15.78 in Extended Height 25.78 in Outside Dia 5.16 in Plunger Dia 2.75 in Base Bolt Circle Dia 3.03 in Base Mounting Thread Size M12x1.75 Center Hole Dia Not Applicable Weight 73.8 lb Bore Dia 3.75 in

Full Specifications

Procurement Details

UNSPSC Code 99999
NAICS Code N/A

Documents
