Standard Duty Ball Bearing Insert, 0.5000 Inch Inside Diameter, 1.5748 Inch Outside Diameter, 0.7480 Inch Inner Ring Width, Eccentric Collar, Relubricatable

NTN BCA® narrow series locking collar bearings have an inner ring that extends on the locking side and is flush on the opposite side. This design offers a cost effective option for light to medium load applications and is particularly well suited to situations in which limited space is available. Designed for shaft mounting using a slip fit to achieve optimum performance the shaft diameter should be maintained with 0.001 in of the normal size. NP series bearings are typically supplied with an eccentric locking collar. BCA® Ball Insert Bearing, Round Bore Standard-Duty, Series: NPC, 12.7 mm Bore, 40 mm OD, 28.6 mm Width, Double Seal Closure, 9600 N Load, Hardened Steel Bearing, Nitrile Rubber Seal, 5000 RPM Maximum, -40 to 120 °C
