Signal Conditioner, Enclosed, For Use With: SC100 Signal Conditioner, Specifications: DIN Rail Mount, 0 to 10 VDC 4 to 20 mA Outputs, 32 to 122 °F, 24 VDC at 500 mA Input Power, 2-Sensors, +/- 5 to 15 V Adjustable For Sensor Excitation, 4.33 in L x 2

Nexen® SC100 signal conditioner provides excitation and signal processing to amplify low voltage sensor signals. Signals are amplified to industry standard voltage/current levels and outputs are suitable for use with indicators, PLCs, PCs and web controls. The SC line offers two sensor channels and supports two different sensor families: differential signal sensors and single ended signal sensors. Differential sensors such as strain gauge load cells are used to measure force or tension. Single ended sensors such as LVDT load cells and web guide sensors are used to measure force, tension or we edge position. Operators can optimize signal conditioner outputs using either the summation of both sensor channels or each channel individually. Nexen® Signal Conditioner, Enclosed, For Use With: SC100 Signal Conditioner, Specifications: DIN Rail Mount, 0 to 10 VDC 4 to 20 mA Outputs, 32 to 122 °F, 24 VDC at 500 mA Input Power, 2-Sensors, +/- 5 to 15 V Adjustable For Sensor Excitation, 4.33 in L x 2.16 in W x 3.32 in H Dimensions
